Features
- Individual split covers
- Compact, pre-bussed, easy to handle, hang and wire
- Bottom and rear branch wiring exits (neutral and ground at bottom only)
- Barriered, sealable compartment for unmetered current carrying parts
- Aluminum/copper lay-in lugs, except 2-socket units
- ANSI 61 light gray electro-deposited paint on zinc coated G90 steel
- Semi-flush with applicable field installed kit
- Without bypass
Specifications
GTIN: 00040892875904
UNSPSC: 39121102
Country of Origin: United States of America (the)
| Weight | 29.3 lbs |
|---|---|
| Feed Type | Bottom/Top |
| Socket Amps | 125 A |
| Mounting Type | Surface |
| Bus Amps | 300 A |
| Phase | 1 |
| Socket Cover Style | Ring |
| BABA Compliant | No |
| Number of Meter Sockets | 3 |
| Wire Size | 2 AWG to 600 kcmil |
| Breaker Type | HQP/MP-T/MP-HT/MP-MT/QP/QPH |
| Voltage Rating | 120 V AC |
| Socket Jaws | 4 |
| Socket Type | Self-Contained |
| Type | 11-Cutout |
| Dimensions | 38.75 in H x 25.42 in W x 7.56 in D |
| Sold as | EACH |
