Siemens SIRIUS ACT A6X30137805 3SU10 Non-Illuminated Round Selector Switch Operator With Front Ring and Laser Labeling, 22 mm, Latching/Rotary Knob Operator, 4 Positions, Sand Gray/White
Siemens SIRIUS ACT A6X30137805 3SU10 Non-Illuminated Round Selector Switch Operator With Front Ring and Laser Labeling, 22 mm, Latching/Rotary Knob Operator, 4 Positions, Sand Gray/White
MPN A6X30137805
ASPN SIEA6X30137805
UPC 804766592171
Description
Features
- Direct connection of the enclosure to AS-interface or IO-link
- Direct connection in the control cabinet to PROFINET, IO-link or AS-interface
- Can be integrated easily via the TIA portal
- Self-holding function of the actuator when mounting
- Twist prevention integrated into patented holder design
- Stackable contact modules
- Self-explanatory and fast installation using one hand
- Components can be mounted with holder removed
- No special tools required, simple size 2 screwdriver (cross-tip DIN ISO 87641PZD1, flat-head DIN ISO 2380-1 A/B 1x4.5) is sufficient
- Text line in upper/lower case, all lines begin with upper case letters
- (4) 90 deg (3/6/9/12 o'clock)
Specifications
GTIN: 00804766592171
UNSPSC: 39122216
Country of Origin: Germany
| Type | Non-Illuminated Round |
|---|---|
| Color | Sand Gray/White |
| Size | 22 mm |
| Contact Mode | Maintained |
| Enclosure Type | NEMA 1/2/3/3R/4/4X/12/13/IP66/IP67/IP69/IP69K |
| Number of Positions | 4 |
| Throw | 4 x 90 deg |
| Operator Type | Rotary |
| Series | 3SU10 |
| Material | Plastic |
| Finish | Matte |
| Temperature Rating | -25 to 70 deg C |
| Bezel/Housing | Metal |
| BABA Compliant | No |
| Sold as | EACH |
