Siemens

Sentron 7KM2200-2EA30-1HA1 PAC2220 3-Phase DIN Rail Mount Measuring Device, 3 to 480 V L-L3 to 276 V N-L, 5 A, LCD Display, Modbus RTU + MID Communication


Description

Sentron Measuring Device, 3-Phase DIN Rail Mount, Series: PAC2220, 3 to 480 V L-L/3 to 276 V N-L, 5 A, LCD Display, Modbus RTU + MID Communication, 107.8 mm L x 96.9 in H

The 7KM PAC2200 measuring devices function as versatile energy meters for the standard mounting rail and indicate the most important measured values directly on the display. Integrated communication interfaces via Modbus TCP, Modbus RTU or M-Bus provide a flexible connection to power monitoring systems. The integrated web server (Modbus TCP version) is used for simple, device-independent visualization of measured values. The devices are incorporated in the familiar and simple system environment of powerconfig and powermanager. The 7KM PAC2200 measuring devices meet the high requirements of IEC 61557-12 with class 1%. International approvals enable use all over the world.

Features

  • Large scope of functions and services
  • Threshold value monitoring and averaging
  • Energy meters for active energy, reactive energy and apparent energy, high and low tariffs, import and export
  • Integration in any energy management system or automation system via Modbus TCP, Modbus RTU or M-Bus digital input and output
  • Mounting on standard mounting rail with 6MW
  • Self-powered, screw terminals

Specifications

GTIN: 00195125034006

UNSPSC: 41113708

Country of Origin: Germany

Voltage Rating
3 to 480 V L-L/3 to 276 V N-L
Dimensions
107.8 mm L x 96.9 in H
Series
PAC2220
Amperage Rating
5 A
Volume
501.1 cubic inches
Communication
Modbus RTU + MID
Display Type
LCD
BABA Compliant
No
Type
3-Phase DIN Rail Mount
Sold as
EACH
