Description
Siemens SIRIUS ACT Non-Illuminated Acoustic Signal Device, Compact Round, Series: 3SU12, 22 mm, Solder Pin, Screw Terminal, NEMA 1/IP20/IP40, Front Panel Mount, Plastic, Black, Environmental Conditions: -25 to 70 deg C Operating, -40 to 80 deg C Storage, 10 to 95% Relative Humidity
SIRIUS ACT is a modular system of pushbuttons and indicator lights for front plate mounting and rear mounted electrical modules. It can be flexibly configured to specific customer requirements and features extensive accessories. For common applications, complete devices are offered.
Features
- Rugged and durable, even in a tough environment, thanks to IP69K protection (including IP66, IP67, IP69)
- High media resistance, for example, to oils, aggressive vapors and caustic solutions
- Easy to operate, thanks to improved haptic properties and illumination
- Fast, single handed installation thanks to retentive actuator function
- Twist prevention integrated into patented holder design
- Alignment arrows and distinct module slots for reliable connection
- No special tools required, simple size 2 screwdriver
- Communication solutions - AS-interface, IO-Link or PROFINET/PROFIsafe
- Can be integrated easily via TIA portal
- Self-holding function of the actuator when mounting
- Stackable contact modules
- Components can be mounted with holder removed
- Mechanical endurance of 10 x 10^6 operating cycles
- Reliable, friction locked fixing with just one screw
- Design stability according to use
- Simple geometry for mounting holes
- 230 VAC operating voltage
- 80 dB at 10 cm distance minimum sound pressure, 2.4 kHz continuous tone
- Without module and holder
Specifications
GTIN: 00804766370458
UNSPSC: 39122216
Country of Origin: Czechia
| Type | Compact Round |
|---|---|
| Terminal Type | Screw |
| Color | Black |
| Size | 22 mm |
| Enclosure Type | NEMA 1/IP20/IP40 |
| Mounting Type | Front Panel |
| Series | 3SU12 |
| Connection Type | Solder Pin |
| Material | Plastic |
| Volume | 423.4 cubic inches |
| Environmental Conditions | -25 to 70 deg C Operating, -40 to 80 deg C Storage, 10 to 95% Relative Humidity |
| BABA Compliant | No |
| Sold as | EACH |
