Siemens SIRIUS 3RA21101KA171BB4 Fuseless Load Feeder Starter, 24 VDC V Coil, Reversing Action, 3 Poles, IP20 Enclosure

Siemens SIRIUS Load Feeder Starter, Fuseless, Series: 3RA2, 690 VAC, 9 to 12.5 A, 50/60 Hz Frequency, 24 VDC Coil, 3 Pole, 3 ph ph, Thread Connection, Reversing Action, Solid-State Overload Relay, 1NO Auxiliary, IP20 Enclosure, Starting Modes: Direct On-Line, 30000000 Cycles Operating Cycles, -20 to 60 deg C Operating, 167 mm H x 45 mm W x 97 mm D Dimensions

The 3RA2 fuseless load feeders consist of the 3RV2 motor starter protector and the 3RT2 electromechanical contactor. The devices are electrically and mechanically connected using pre-assembled assembly kits (link modules, wiring kits and standard mounting rail or busbar adapters). Around 500 pre-assembled 3RA2 combinations of these innovative 3RT2 controls and 3RV2 protection equipment can be ordered for direct on line and reversing starting of standard three phase motors up to 32 A (approximately 15 kW/400 VAC). In the 3RA2 load feeder, the 3RV2 motor starter protector is responsible for overload and short circuit protection. Back up protective devices, such as melting fuses or limiters, are superfluous here, as the motor starter protector is short circuit proof up to 150 kA at 400 VAC.
