Description
Siemens Sentron Cylindrical Fuse Link, Slow, 4 A, 600 VAC, 200 kA Interrupt, Class: CC, Ceramic/Plastic, 10.3 mm Dia x 38.1 mm L Body Size
Class CC fuses are used for "branch circuit protection". The characteristic of the fuse links is designed and tested to comply with the US National electrical Code NEC 210.20(A). This means that when subject to continuous operation, only 80% of the rated current is permissible as operational current. An operational current of 100% of the rated current 30 A is only permissible short time. The devices are prepared for the inscription labels of the ALPHA FIX terminal blocks 8WH8120-7AA15 and 8WH8120-7XA05.
Features
- For switchboard assemblies and machine manufacturers who export their systems to the USA or Canada
- Easier export due to UL and CSA approvals for typical applications
- Modern design with touch protection to BGV A3 ensures safe installation
- For the protection of control transformers, reactors, inductances
- Significantly slower than the minimum requirements specified by UL for Class CC fuses of 12 s at 2 x In
Specifications
GTIN: 00040892779851
UNSPSC: 39121626
Country of Origin: Germany
| Type | Slow |
|---|---|
| Interrupt Rating | 200 kA |
| Voltage Rating | 600 V AC |
| Class | CC |
| Body Size | 10.3 mm Dia x 38.1 mm L |
| Material | Ceramic/Plastic |
| Amperage Rating | 4 A |
| BABA Compliant | No |
| Sold as | EACH |
