Siemens 1FW32081FE727AA0 1FW3 Complete Water Cooling Torque Motor, IP54 Enclosure, 316, 337, 357 V, 140, 150, 160, 170 rpm Speed, Belt Mounting
Siemens 1FW32081FE727AA0 1FW3 Complete Water Cooling Torque Motor, IP54 Enclosure, 316, 337, 357 V, 140, 150, 160, 170 rpm Speed, Belt Mounting
MPN 1FW32081FE727AA0
ASPN SIE1FW32081FE727AA0
UPC 195125298057
Description
Features
- High torque, compact design, and low construction volume
- Optimized mechatronic solution
- Highest degree of stiffness
- High speeds possible
- Innovative machine concepts are possible
- Increased productivity and quality
- The right design for every application
- Large power range
- Hollow shaft, plug-on shaft, or solid shaft
- Different encoder types for speed control and high-precision positioning
- Excellent performance
- Maximum speeds up to 1800 rpm
- Excellent rotational accuracy
- High dynamic response, i.e. short ramp-up times
- The ideal motor for energy-saving solutions
- Simple encoder replacement without requiring any readjustment for plug-on and solid shafts
Specifications
GTIN: 00195125298057
UNSPSC: 26101109
Country of Origin: Germany
| Type | Complete Water Cooling |
|---|---|
| Torque Rating | 2000 Nm |
| Voltage Rating | 316/337/357 V |
| Speed | 140, 150, 160, 170 rpm |
| Enclosure Type | IP54 |
| Mounting Type | Belt |
| Series | 1FW3 |
| Bearing Type | Standard |
| Amperage Rating | 84 A |
| Sold as | EACH |
