Description
Siemens 1FT71055AB701CH0, Synchronous Motor, 1FT, 13, 1500 Speed, 1 Speed, IP64 Enclosure, Rotatable Rotation, 42 Torque, IM V1/IMV3 Mounting
SIMOTICS S Synchronous motor 1FT7, M0=50Nm (100K) NN=1500rpm, PN=6.60kW Naturally cooled Frame size IMB 5 (IM V1, IM V3) recessed flange (more compact) POWER CONNECTOR ROTATABLE ABSOLUTE ENCODER 24 BITS 12 BIT MULTITURN WITH DRIVE-CLIQ INTERFACE (ENCODER AM24DQI) PLAIN SHAFT, WITH HOLDING BRAKE; ACCURACY TOLERANCE N VIBRATION SEVERITY GRADE A, DEGREE OF PROTECTION IP 64
Features
- Low moment of inertia and high overload capability of the motor
- High-resolution encoder with fast scanning
- Current controller clock cycle of 62.5 and a pulse frequency of 8 kHz of the servo converter
Specifications
GTIN: 00195125189416
UNSPSC: 26101109
Country of Origin: Germany
| Type | Synchronous Motor |
|---|---|
| Torque Rating | 42 |
| Rotation | Rotatable |
| Weight | 8 lbs |
| Speed | 1500 |
| Enclosure Type | IP64 |
| Number of Speeds | 1 |
| Mounting Type | IM V1/IM V3 |
| Series | 1FT |
| Amperage Rating | 13 |
| BABA Compliant | No |
| Sold as | Each |
