Panduit® Pan-Net® TX6000™ PFP6C04BU-UG Cat 6 Plenum(CMP) Shielded Cable, Reel Packaging, 80 V, (4 Pairs) 23 AWG F/UTP Solid Copper Conductor, 1000 ft L


Description

Panduit® Pan-Net® TX6000™ Cable, Cat 6 Plenum(CMP) Shielded, Reel, 80 V, 4 Pairs Conductors, F/UTP Solid Copper Conductor, 23 AWG Conductor, 7 mm Outside Dia, 1000 ft Length, Flame Retardant, FEP Insulation, PVC Jacket, Blue Jacket, 167 deg F

Category 6 Cable shall exceed IEC 61156-5 and ANSI/TIA-568.2-D Category 6 component standards. The conductors shall be 23 AWG construction with FEP (CMP) or polyolefin (CMR) insulation. The copper conductors shall be twisted in pairs, separated by a cross divider and all four pairs shall be covered with an overall foil and a low smoke, flame-retardant (CMP) or flame-retardant (CMR) PVC jacket.

Features

  • Descending length cable markings - easy identification of remaining cable reduces installation time and cable scrap
  • Overall foil - provides superior structural integrity and reduces external interference to ensure exceptional Cable performance at all swept frequencies
  • Third party tested - cable has been tested as part of the TX6000™ Category 6 F/UTP copper cabling system by an independent laboratory and complies with the electrical channel requirements of ISO 11801 class E and ANSI/TIA-568.2-D Category 6 standards

Specifications

GTIN: 00613056571181

UNSPSC: 26121634

Country of Origin: Viet Nam

Packaging Type
Reel
Outside Diameter
7 mm
Jacket Material
PVC
Insulation Material
FEP
Conductor Type
F/UTP Solid Copper
Voltage Rating
80 V
Conductor Size
23 AWG
Length
1000 ft
Jacket Color
Blue
Number of Conductors
4 Pairs
Resistance
Flame Retardant
Temperature Rating
167 deg F
Type
Cat 6 Plenum(CMP) Shielded
Sold as
