Wiring Device-Kellems Twist-Lock L1620P 3-Phase Grounding Standard Sized Cord Mount Locking Male Plug, 480 VAC, 20 A, 3 Poles, 4 Wires, Black
Wiring Device-Kellems Twist-Lock L1620P 3-Phase Grounding Standard Sized Cord Mount Locking Male Plug, 480 VAC, 20 A, 3 Poles, 4 Wires, Black
MPN L1620P
ASPN HUBL1620P
UPC 783585835921
Description
Features
- Visible NEMA ratings
- Captive assembly screws
- Supertough® nylon body
- Impact modified nylon blade/contact holder
- Brass contacts/blade
- Withstands 3500 VAC per UL 498 dielectric voltage
- 600 VAC or 250 VDC maximum working voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498
- Minimum 4.8 times rated current for 100 cycles overload
- Terminals identified in accordance with UL 498 (brass, white, green)
- 18 to 8 AWG flexible cord
- Ratings and NEMA identification are permanently marked on device
- Indoor dry unless protected by additional means
- 14 to 10 AWG wire
Specifications
GTIN: 00783585835921
UNSPSC: 39121403
Country of Origin: China
| Type | 3-Phase Grounding Standard Sized Cord Mount |
|---|---|
| Terminal Type | Screw |
| Number of Wires | 4 |
| Number of Poles | 3 |
| Color | Black |
| Grade | Commercial/Industrial |
| Voltage Rating | 480 VAC |
| Weight | 6.9 lbs |
| Width | 3.3 in |
| NEMA Rating | L16-20P |
| Material | Composite |
| Amperage Rating | 20 A |
| Temperature Rating | -40 to 60 deg C |
| BABA Compliant | No |
| Sold as | EACH |
