A-B 194L-E40-7303 40 A 194L Load Sw
A-B 194L-E40-7303 40 A 194L Load Sw
MPN 194L-E40-7303
ASPN AB194LE407303
UPC 611320923247
Description
Features
- Rated power (Pe)3-poles, 3-phase: 10 Hp @ 240V per UL (CSA)
- Rated power (Pe)3-poles, 3-phase: 25 Hp @ 480V per UL (CSA)
- Rated power (Pe)3-poles, 3-phase: 25 Hp @ 600V per UL (CSA)
- Rated power (Pe)2-poles, 1-phase: 2 Hp @ 120V per UL (CSA)
- InstallationOpen-front/door
Specifications
GTIN: 00611320923247
UNSPSC: 32151801
| Invoice Description - English | 40 A 194L Load Switch |
|---|---|
| Safety Data Sheet (SDS) Flag | N |
| Number of Poles | 3 Poles |
| Size | 40 A |
| Special Features | Reversing 1-0-2 45° |
| Contact Configuration | Reversing 1-0-2 45°, M |
| BABA Compliant | No |
| Height (Imperial) | 3.1902 |
| Height UOM (Imperial) | IN |
| Length (Imperial) | 3.4598 |
| Length UOM (Imperial) | IN |
| Width (Imperial) | 3.0299 |
| Width UOM (Imperial) | IN |
