A-B 140G-H6C3-C25-MT 140G 125A H Fr
A-B 140G-H6C3-C25-MT 140G 125A H Fr
MPN 140G-H6C3-C25-MT
ASPN AB140GH6C3C25MT
UPC 887172662010
Description
Features
- Vibration2...13.2 Hz ±1 mm; 13.2...100 Hz ±0.7 G
- ShockPeak acceleration: 150 m/s^2 peak; pulse duration 11 ms
- Voltage for reverse-fed circuit breaker, max480V AC per IEC
- Voltage for reverse-fed circuit breaker, max480V AC per UL/CSA
- Operational voltage (Ue)79% of voltage rating @ 4000 meter (13,120 ft) altitude
Specifications
GTIN: 00887172662010
UNSPSC: 39121616
| Invoice Description - English | 140G 125A H Frame Molded Case Ckt-Bkr |
|---|---|
| Safety Data Sheet (SDS) Flag | N |
| Trip Type | T/M - Fixed Thrm / Fixed Mgntc |
| Interrupt Rating | 65 kA at 480V |
| Number of Poles | 3 Poles |
| Current Rating | 25A |
| Trip Range | 80 Percent MCCB |
| Frame | 125A H Frame |
| Interrupt-Rating--240VAC | 65 kA at 480V |
| BABA Compliant | No |
| Height (Imperial) | 7.0000 |
| Height UOM (Imperial) | IN |
| Length (Imperial) | 9.5000 |
| Length UOM (Imperial) | IN |
| Width (Imperial) | 8.5000 |
| Width UOM (Imperial) | IN |
