A-B 140G-G6C3-C40-AA 140G 125A G Fr
A-B 140G-G6C3-C40-AA 140G 125A G Fr
MPN 140G-G6C3-C40-AA
ASPN AB140GG6C3C40AA
UPC 887172937835
Description
Features
- Rated service short-circuit breaking capacity (Ics)IEC 60947-2: 75% lcu @ 500V DC, 3-poles in series, thermal-magnetic trip unit only
- Rated service short-circuit breaking capacity (Ics)IEC 60947-2: 50% lcu @ 690V AC, 50/60 Hz
- Rated service short-circuit breaking capacity (Ics)IEC 60947-2: 75% lcu @ 250V DC, 2-poles in series, thermal-magnetic trip unit only
- Thermal trip rating, max38 A @ ambient temperature 50 °C
- Thermal trip rating, max35 A @ ambient temperature 60 °C
Specifications
GTIN: 00887172937835
UNSPSC: 39121616
| Invoice Description - English | 140G 125A G Frame Molded Case Ckt-Bkr |
|---|---|
| Safety Data Sheet (SDS) Flag | N |
| Trip Type | T/M - Fixed Thrm / Fixed Mgntc |
| Interrupt Rating | 65 kA at 480V |
| Number of Poles | 3 Poles |
| Current Rating | 40A |
| Trip Range | 80 Percent MCCB |
| Frame | 125A G Frame |
| Interrupt-Rating--240VAC | 65 kA at 480V |
| BABA Compliant | No |
| Height (Imperial) | 5.2500 |
| Height UOM (Imperial) | IN |
| Length (Imperial) | 5.6000 |
| Length UOM (Imperial) | IN |
| Width (Imperial) | 5.1000 |
| Width UOM (Imperial) | IN |
