Siemens Sentron E12HFD63B250 Type HFD6 Low Voltage Molded Case Circuit Breaker, 600 VAC, 250 A, 25 kA Interrupt, 3 Poles, ThermalMagnetic Trip


Description

Siemens Sentron Molded Case Circuit Breaker, Type HFD6 Low Voltage, 600 VAC, 250 A, 50/60 Hz Frequency, 25 kA Interrupt, FD Frame, Thermal/Magnetic Trip, 3 Pole, Line/Load Lug Connection, 6 AWG to 350 kcmil/4 AWG to 350 kcmil Wire, NEMA 12 Enclosure, -25 to 75 deg C, 39 in L x 15 in W x 9 in H Dimensions

Siemens Sentron™ series circuit breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens Sentron™ series circuit breakers are available in nine frame sizes from 125 A to 2000 A.

Features

  • Field installable external accessories
  • Series connected short circuit ratings
  • FD frame with high breaking capacity in a NEMA type 12 enclosure

Specifications

GTIN: 00783643294561

UNSPSC: 39121601

Alternative Part Number: 9576440

Country of Origin: Mexico

Type
Type HFD6 Low Voltage
Trip Type
Thermal/Magnetic
Wire Size
6 AWG to 350 kcmil/4 AWG to 350 kcmil
Interrupt Rating
25 kA
Number of Poles
3
Frequency Rating
50/60 Hz
Voltage Rating
600 VAC
Enclosure Type
NEMA 12
Dimensions
39 in L x 15 in W x 9 in H
Connection Type
Line/Load Lug
Amperage Rating
250 A
Temperature Rating
-25 to 75 deg C
Frame
FD
BABA Compliant
No
Sold as
EACH
