Sentron™ 3VA25107HN320AA0 Low Voltage Molded Case Circuit Breaker, 690 VAC, 1000 A, 19 kA at 690 V, 65 kA at 500 V, 70 kA at 440 V, 85 kA at 415 V, 150 kA at 240 V Interrupt, 3 Poles, ETU350 Electronic Trip
Sentron™ 3VA25107HN320AA0 Low Voltage Molded Case Circuit Breaker, 690 VAC, 1000 A, 19 kA at 690 V, 65 kA at 500 V, 70 kA at 440 V, 85 kA at 415 V, 150 kA at 240 V Interrupt, 3 Poles, ETU350 Electronic Trip
MPN 3VA25107HN320AA0
ASPN SIE3VA25107HN320AA0
UPC 195125111561
Description
Features
- Compliance with global standards and certifications
- Minimum space requirement thanks to the compact design
- Extensive selection of internal accessories (auxiliary and alarm switches, shunt trips), that are universal to the product line
- Power metering and communication capability with Modbus, PROFIBUS, PROFINET protocols
- Minimal effort for planning and configuration as a result of extensive CAD data
- Knowledge manager- technical information on a specific device can be accessed directly via QR code
- Without auxiliary releases and auxiliary alarm switches
Specifications
GTIN: 04042948835845
UNSPSC: 39121616
Alternative Part Number: 16876465
Country of Origin: Czechia
| Type | Low Voltage |
|---|---|
| Number of Poles | 3 |
| Frequency Rating | 50/60 Hz |
| Enclosure Type | IP40 |
| Trip Range | 10000 A |
| Temperature Rating | -25 to 70 deg C |
| BABA Compliant | No |
| Connection Type | Lug Terminal/Nut Keeper |
| Trip Type | ETU350 Electronic |
| Amperage Rating | 1000 A |
| Voltage Rating | 690 VAC |
| Frame | 3VA25 IEC 1000 A |
| Interrupt Rating | 19 kA at 690 V, 65 kA at 500 V, 70 kA at 440 V, 85 kA at 415 V, 150 kA at 240 V |
| Dimensions | 8.3 in W x 4.7 in D x 12.6 in H |
| Sold as | EACH |
