Description
SIRIUS IEC Control Relay, 50/60 Hz Frequency, 24 VDC Coil, 4NO Contact Form, 6/1 A at 230/690 VAC, 10/1 A at 24/220 VDC Contact, 4 Pole, Snap-On Mounting, Threaded Terminal, IP20 Enclosure, -25 to 60 deg C, 57.5 mm H x 90 mm W x 72 mm D Dimensions
Features
- S00 frame
- 6 A/1 A at 230/690 VAC AC-15, 10 A/1A at 24/220 VDC DC-12
- A600/Q600 NEMA designation
Specifications
GTIN: 00754554489056
UNSPSC: 39122331
Country of Origin: Germany
| Terminal Type | Threaded |
|---|---|
| Number of Poles | 4 |
| Frequency Rating | 50/60 Hz |
| Enclosure Type | IP20 |
| Dimensions | 57.5 mm H x 90 mm W x 72 mm D |
| Coil Voltage | 24 VDC |
| Mounting Type | Snap-On |
| Temperature Rating | -25 to 60 deg C |
| BABA Compliant | No |
| Contact Rating | 6/1 A at 230/690 VAC, 10/1 A at 24/220 VDC |
| Contact Form | 4NO |
| Sold as | EACH |
