GE Spectra RMS™ SEHA24AT0100 Type SEH Molded Case Circuit Breaker, 480 VAC, 100 A, 25/65 kA Interrupt, 2 Poles, Electronic LSI Trip
GE Spectra RMS™ SEHA24AT0100 Type SEH Molded Case Circuit Breaker, 480 VAC, 100 A, 25/65 kA Interrupt, 2 Poles, Electronic LSI Trip
MPN SEHA24AT0100
ASPN GESEHA24AT0100
UPC 783164211160
Description
Features
- Snap-in lugs (in E and F frames), lug installation requires no disassembly or removal of cover
- An industry first, common internal accessories, regardless of frame rating, you only have to stock one type of accessory, reduces inventory
- Unique, short time function tracks the adjustable instantaneous setting for greater motor and transformer protection, standard for all frames
- Current limiting by design
- Accessory leads can be either right or left exit and thanks to the side and rear channels, no added space is required for lead exit
- Digital RMS trip system standard, true RMS sensing means accurate response to the high harmonic content current waveforms produced by SCR drives, welders, arc furnaces, computer power supplies and discharge type lighting, all without nuisance tripping
- (1) 12 to 3/0 AWG copper, (1) 12 to 3/0 AWG aluminum wire range
- 25 kA at 277 VAC, 25 kA at 480 VAC, 65 kA at 120 VAC, 65 kA at 120/240 VAC, 65 kA at 240 VAC interrupt rating
- Standard continuous load rating
Specifications
GTIN: 00783164211160
UNSPSC: 39121601
| Number of Poles | 2 |
|---|---|
| Frequency Rating | 50/60 Hz |
| Voltage Rating | 480 VAC |
| Weight | 18 lbs |
| Enclosure Type | NEMA 1/3R/4/4X/12 |
| Mounting Type | Panel |
| Phase | 3 |
| Amperage Rating | 100 A |
| Temperature Rating | 104 deg F |
| BABA Compliant | No |
| Connection Type | Lug |
| Frame | SE150 |
| Trip Type | Electronic LSI |
| Wire Size | 12 to 3/0 AWG |
| Interrupt Rating | 25/65 kA |
| Actuator Type | Toggle |
| Type | Type SEH |
| Dimensions | 4.12 in W x 3.38 in D x 6.31 in H |
| Sold as | EACH |
