Description
ABB Feed-Thru Terminal Block, 1000 VAC, 24 A, 26 to 12 AWG Stranded Wire, 11 mm Wire Strip Length, Spring Clamp Terminal, 5.2 mm Spacing, DIN Rail Mount, PI Spring, -55 to 110 deg C, Red, 40.2 mm L x 5.2 mm W x 80.2 mm H
Features
- 2.5 sq-mm rated cross-section
- Feed-through function
- A2/2.3 mm dia guage
- 1 s 300 A rated short-time withstand current
- 8000 VAC rated impulse withstand voltage
- 2200 VAC dielectric test voltage
- 3 deg pollution
- 1 W power loss
- Polyamide insulation material
- 100 kA short circuit current rating
- 1x 26 to 12 AWG spring clamp/rigid, 1x 26 to 14 AWG spring clamp/with insulated ferrrule, 1x 26 to 14 AWG spring clamp/without insulated ferrule main circuit connecting capacity UL/CSA
- -55 to 110 deg C storage temperature
Specifications
GTIN: 00888614180284
UNSPSC: 39121410
Alternative Part Number: ZK2.5-4P-RD
Country of Origin: France
| Wire Size | 26 to 12 AWG Stranded |
|---|---|
| Color | Red |
| Wire Strip Length | 11 mm |
| Mounting Type | DIN Rail |
| Connection Type | PI Spring |
| Temperature Rating | -55 to 110 deg C |
| Amperage Rating | 24 A |
| Spacing | 5.2 mm |
| Dimensions | 40.2 mm L x 5.2 mm W x 80.2 mm H |
| Voltage Rating | 1000 VAC |
| Terminal Type | Spring Clamp |
| Sold as |
