Universal™ Basic-12™ B260I120M-A000I Electronic Fluorescent Ballast, T12T12ES Lamp, 96 W Lamp, 120 VAC, Instant, 0.88 Ballast Factor


Description

Universal Basic-12 Electronic Fluorescent Ballast, T12/T12ES Lamp, 96 W Lamp, 105 W Wattage, 120 VAC, 0.9 A, 60 Hz Frequency, Instant Start, 60 deg F Minimum Starting, Total Harmonic Distortion: 0.95, No Dimmable, 2 Lamps, Ballast Factor: 0.88, NEMA 1 Enclosure, 167 deg F, 9.5 in L x 1.7 in W x 1.18 in H Dimensions

For more than 30 years, the lighting industry has relied on our Triad® brand for the most specified, most installed, most reliable electronic ballasts in the business. The Triad® line offers advantages like installer - friendly universal input voltage, which ensures that you have the right voltage ballast every time and maximum energy savings for long cycle operations. And our ULTim8® and AccuStart™ ballasts feature high efficiency designs and programmed start technology that dramatically enhances lamp life.

Features

  • Passive power factor correction
  • Parallel lamp operation
  • T12ES lamp type

Specifications

GTIN: 00768386242222

UNSPSC: 39101901

Country of Origin: Mexico

Dimmable
No
Number of Lamps
2
Wattage
105 W
Frequency Rating
60 Hz
Voltage Rating
120 VAC
Weight
0.1 lbs
Enclosure Type
NEMA 1
Dimensions
9.5 in L x 1.7 in W x 1.18 in H
Lamp Type
T12/T12ES
Lamp Wattage
96 W
Temperature Range
167 deg F
Amperage Rating
0.9 A
Start Type
Instant
Volume
0
Total Harmonic Distortion
<30 %
Minimum Starting Temperature
60 deg F
Power Factor
>0.95
Ballast Factor
0.88
BABA Compliant
No
Sold as
EACH
