Triad® B259IUNVHP-A000I Electronic Fluorescent Ballast, T8T88FT Lamp, 96 W Lamp, 120 to 277 VAC, Instant, 0.88 Ballast Factor


Description

Triad Electronic Fluorescent Ballast, T8/T88FT Lamp, 96 W Lamp, 110/113 W Wattage, 120 to 277 VAC, 0.95 A, 50/60 Hz Frequency, Instant Start, 32 deg F Minimum Starting, Total Harmonic Distortion: 0.98/0.99, No Dimmable, 2 Lamps, Ballast Factor: 0.88, NEMA 1 Enclosure, 167 deg F, 9.5 in L x 1.7 in W x 1.18 in H Dimensions

For more than 30 years, the lighting industry has relied on our Triad® brand for the most specified, most installed, most reliable electronic ballasts in the business. The Triad® line offers advantages like installer - friendly universal input voltage, which ensures that you have the right voltage ballast every time and maximum energy savings for long cycle operations. And our ULTim8® and AccuStart™ ballasts feature high efficiency designs and programmed start technology that dramatically enhances lamp life.

Features

  • Parallel lamp operation
  • Active power factor correction

Specifications

GTIN: 00768386228233

UNSPSC: 39101901

Country of Origin: Mexico

Frequency Rating
50/60 Hz
Weight
2.5 lbs
Enclosure Type
NEMA 1
Minimum Starting Temperature
32 deg F
BABA Compliant
No
Number of Lamps
2
Ballast Factor
0.88
Power Factor
>0.98/0.99
Total Harmonic Distortion
<10 %
Volume
57 CF
Start Type
Instant
Temperature Range
167 deg F
Lamp Wattage
96 W
Lamp Type
T8/T88FT
Dimensions
9.5 in L x 1.7 in W x 1.18 in H
Voltage Rating
120 to 277 VAC
Wattage
110/113 W
Dimmable
No
Amperage Rating
0.95 A
Sold as
EACH
