Description
Color-Keyed® Compression Lug, 1-Hole, Series: ATL, Stranded Aluminum Conductor, 1/0 AWG Conductor, 35 kV, 5/16 in Stud, Straight Tongue, 1 in L x 7/8 in W x 3/16 in THK Tongue, 2-17/32 in Overall Length, Standard Barrel, 1-5/32 in L Barrel, Specifications: Tin Plated, Aluminum, Tan
Blackburn® is a complete and reliable line of overhead, grounding, mechanical and compression connectors that respond to a broad range of construction needs.
Features
- Specifically designed for use with aluminum conductors (concentric, compressed or compact)
- Also listed for use with copper conductors
- Made of high conductivity seamless aluminum tubing
- Chamfered barrels for ease of installation
- Can be used for medium voltage application up to 35 kV provided proper insulation techniques are used
- Color coded for quick, easy die identification
- Prefilled with oxide-inhibitor
Specifications
GTIN: 00783786610952
UNSPSC: 39121405
Discontinued Manufacturer Part Number: 7TAH007610R0062
Country of Origin: Mexico
| Type | 1-Hole |
|---|---|
| Color | Tan |
| Overall Length | 2-17/32 in |
| Tongue Type | Straight |
| Conductor Type | Stranded Aluminum |
| Barrel Type | Standard |
| Voltage Rating | 35 kV |
| Specifications | Tin Plated |
| Stud Size | 5/16 in |
| Conductor Size | 1/0 AWG |
| Tongue Size | 1 in L x 7/8 in W x 3/16 in THK |
| Series | ATL |
| Material | Aluminum |
| BABA Compliant | No |
| Barrel Size | 1-5/32 in L |
| Sold as | EACH |
