Southwire® 411020552 Type MTW Building Wire, 600 VAC, (1) 16 AWG Bare Copper Conductor, 500 ft L, Yellow
Southwire® 411020552 Type MTW Building Wire, 600 VAC, (1) 16 AWG Bare Copper Conductor, 500 ft L, Yellow
MPN 411020552
ASPN SW411020552
UPC 29892253066
Description
Features
- 4.18 Ohm/1000 ft nominal DC resistance per conductor at 20 deg C
- 13.2 lb/1m ft nominal cable weight
- Cable consists of one bare copper conductor with integral insulation and jacket
Specifications
GTIN: 00029892253066
UNSPSC: 26121636
Country of Origin: United States of America (the)
| Voltage Rating | 600 VAC |
|---|---|
| Width | 2 in |
| BABA Compliant | No |
| Weight | 7.2 lbs |
| Conductor Type | Bare Copper |
| Insulation Material | PVC |
| Jacket Color | Yellow |
| Amperage Rating | 14 A |
| Temperature Rating | -20 to 105 deg C |
| Outside Diameter | 0.12 in |
| Conductor Size | 16 AWG |
| Length | 500 ft |
| Number of Conductors | 1 |
| Strands | 26 |
| Type | Type MTW |
| Resistance | 4.18 Ohm |
| Sold as |
