Siemens PowerMod™ WMM51225RJ 6-Cutout 3-Wire Type WMM Extra Jaw Insulated Meter Stack, 225 A, Underground Feed, 120/240 VAC, 1200 A Bus


Description

Siemens PowerMod™ Meter Stack, 6-Cutout 3-Wire Type WMM Extra Jaw Insulated, Underground Feed, 120/240 VAC, 1200 A Bus, 225 A Socket, 5 Meter Sockets, 1, Ringless Socket Cover Style, 5 Socket Jaws, QP/MP-T/QPH/HQP/MP-HT/MP-MT/QS/QSH/QSHH/HQS/HQSH Breaker, NEMA 3R Enclosure, Rail/Quick Roll Mounting, 61.313 in H x 16.094 in W x 8.094 in D

Power Mod™ core offering of residential meter stacks, type WMM, offers the widest product offering and flexibility in the industry. Each meter stack houses the QuickSystem™ features to maximize productivity and minimize labor costs. To aid in productivity and labor cost reductions our 225 A meter stacks feature a new breaker, the "QS". The QS breaker adds to the Siemens exclusive feature set on our new 225 A residential meter stacks.

Features

  • Exclusive knockout plate offers flexibility when pulling wires to the stack
  • New breaker supports keep breakers level and straight
  • Moveable neutrals and grounds to save wire
  • QuickSystem™ features all designed with the contractor in mind
  • 1-phase 3-wire solid neutral incoming and outgoing
  • Without bypass
  • Field installed 5th jaw ECMF5, 5th jaw can be isolated if needed

Specifications

GTIN: 00040892571479

UNSPSC: 39121102

Country of Origin: United States of America (the)

Socket Jaws
5
Voltage Rating
120/240 V AC
Weight
0
Feed Type
Underground
Breaker Type
QP/MP-T/QPH/HQP/MP-HT/MP-MT/QS/QSH/QSHH/HQS/HQSH
Number of Meter Sockets
5
Enclosure Type
NEMA 3R
Socket Amps
225 A
Mounting Type
Rail/Quick Roll
Bus Amps
1200 A
Phase
1
Socket Cover Style
Ringless
BABA Compliant
No
Dimensions
61.313 in H x 16.094 in W x 8.094 in D
Type
6-Cutout 3-Wire Type WMM Extra Jaw Insulated
Sold as
EACH
