Siemens TPS3S151KVX02 TPS3 15 Type 2 External Low Voltage Non-Metallic Standard Mode Surge Protective Device With Surge Counter, 400Y/230 VAC, 47 to 63 Hz, 200 kA SCCR, 3 Phase

Siemens Surge Protective Device, Type 2 External Low Voltage Non-Metallic Standard Mode, Series: TPS3 15, 400Y/230 VAC Electrical Rating, 47 to 63 Hz Frequency, 4+G Wires, 200 kA Short Circuit, 1000 kA Peak Surge Current, 20 kA Nominal Discharge, Modes of Protection: L-N, L-G, N-G, L-L, <1 ns Response, LED/Audible Alarm Indicator, 3 ph, Environmental Conditions: -15 to 140 deg F Operating, 0 to 95% Non-Condensing Relative Humidity, NEMA 4X Enclosure, Wall Mounting, Load Terminal, Gray, 20 in L x 20 in W x 7 in H Dimensions

TPS3 15 are UL 1283 listed incorporating EMI/RFI or sine wave tracking filtering designed to condition low energy L-N coupled noise. When installed at the electrical service entrance, it can be used for UL 96A compliance (20 kA In). Standard monitoring includes protection status indication LEDs, audible alarm and dry contacts. Complete protection is intact when the status indicators are illuminated. When protection is lost, the status indicator will extinguish, the red service light will illuminate and the dry contacts will change state. An optional surge counter is available. A new diagnostic feature integrated within the TPS3 15 is Ground Integrity Monitoring or (GIM) diagnostic indication circuit. Ground Integrity Monitoring or (GIM) diagnostics monitors the health of the electrical system's neutral to ground bond. If voltage is seen across neutral and ground, the phase indicators will remain illuminated, while the red service light begins to flash alerting the end user that the electrical system grounding needs to be checked and serviced. This feature can be remotely monitored via the dry contact outputs. Siemens TPS3s are one of the first in the industry to offer this power quality safety and performance indication.
