Siemens SCTSCM0200U Low Voltage Medium Split Core Current Transformer With 1-1/4 in Window Opening, 200 A Primary, 50 to 400 Hz, 600 VAC


Description

Siemens Current Transformer, Low Voltage Medium Split Core, 200 A Primary Current, 600 VAC, 50 to 400 Hz, 1% Accuracy, 105 deg F, Epoxy Housing, 3.35 in H x 3.25 in W x 1 in D

Siemens split core current transformers (CTs) provide linear output voltage that is directly proportional to the input current. These transformers are safely and easily installed over existing electrical power lines without disconnecting the lines or interrupting service. Siemens energy monitoring components are used for a variety of applications including building automation, tenant sub metering, performance verification, energy management and new technology assessment. These devices are targeted for use with the Siemens MD series power meters.

Specifications

GTIN: 00804766159510

UNSPSC: 41113708

Country of Origin: United States of America (the)

Frequency Rating
50 to 400 Hz
Voltage Rating
600 V AC
Weight
1.2 lbs
Dimensions
3.35 in H x 3.25 in W x 1 in D
Housing Material
Epoxy
Temperature Rating
105 deg F
BABA Compliant
No
Primary Current
200 A
Accuracy
1%
Type
Low Voltage Medium Split Core
Sold as
EACH
