Siemens Sentron LXD63B500HLSN Molded Case Circuit Breaker, 600 VAC, 500 A, 25 kA Interrupt, 3 Poles, ThermalMagnetic Trip


Description

Siemens Sentron Molded Case Circuit Breaker, 600 VAC, 500 A, 50/60 Hz Frequency, 25 kA Interrupt, LD Frame, Thermal/Magnetic Trip, 3000 to 6000 A Trip, 3 Pole, Line/Load Lug Connection, 3/0 AWG to 500 kcmil Cu/4/0 AWG to 500 kcmil Al Wire, 40 deg C, 7 in L x 9 in W x 13 in H Dimensions

SiemensSentronSeriesCircuit Breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens SentronSeries circuit breakers are available in nine frame sizes from 125 to 2000 A.

Features

  • Field installable external accessories
  • Series connected short circuit ratings
  • 100% rated frames
  • Many sizes for motor circuit protectors and molded case switches
  • Non-interchangeable
  • 120 VAC shunt trip

Specifications

GTIN: 00783643968899

UNSPSC: 39121601

Country of Origin: Mexico

Trip Type
Thermal Magnetic
Wire Size
3/0 AWG to 500 kcmil Cu/4/0 AWG to 500 kcmil Al
Interrupt Rating
25 kA
Number of Poles
3
Frequency Rating
50/60 Hz
Voltage Rating
600 V AC
Weight
1.8 lbs
Width
17 in
Dimensions
7 in L x 9 in W x 13 in H
Trip Range
3000 to 6000 A
Connection Type
Line/Load Lug
Amperage Rating
500 A
Temperature Rating
40 deg C
Frame
LD
BABA Compliant
No
Sold as
EACH
