Siemens SpeedFax™ HQR22B100 Molded Case Circuit Breaker, 240 VAC, 100 A, 65 kA Interrupt, 2 Poles, Thermal/Magnetic Trip
Siemens SpeedFax™ HQR22B100 Molded Case Circuit Breaker, 240 VAC, 100 A, 65 kA Interrupt, 2 Poles, Thermal/Magnetic Trip
MPN HQR22B100
ASPN SIEHQR22B100
UPC 804766136320
Description
Specifications
GTIN: 00804766136320
UNSPSC: 39121601
Country of Origin: Mexico
| Trip Type | Thermal Magnetic |
|---|---|
| Wire Size | 3 AWG to 300 kcmil Cu/6 AWG to 350 kcmil Al/Cu |
| Interrupt Rating | 65 kA |
| Number of Poles | 2 |
| Frequency Rating | 50/60 Hz |
| Voltage Rating | 240 V AC |
| Weight | 49 lbs |
| Enclosure Type | NEMA 1/3R |
| Dimensions | 7 in H x 3 in W x 2.53 in D |
| Amperage Rating | 100 A |
| Temperature Rating | 40 deg C |
| Frame | QR |
| BABA Compliant | No |
| Sold as | EACH |
