Siemens SpeedFax HFK3K250B VL Series Low Voltage Molded Case Circuit Breaker With LCD Display, Ground Fault Alarm, 600Y347 VAC, 250 A, 18 to 65 kA Interrupt, 3 Poles, Electronic Trip

Siemens SpeedFax Molded Case Circuit Breaker, Low Voltage, Series: VL Series, 600Y/347 VAC, 250 A, 50/60 Hz Frequency, 18 to 65 kA Interrupt, FG Frame, Electronic Trip, 3 Pole, Standard Load End Lug Connection, 4 AWG to 350 kcmil Al/Cu Wire, 40 deg C, 7.3 in H x 4.1 in W x 3.4 in D Dimensions

Siemens VL Molded Case Circuit Breakers utilize a compact and modular design which can be configured to suit a wide range of ratings from 30 A up to 1600 A. Designed for global requirements, most breakers include the world's major standards and markings such as UL, CSA, NOM, IEC, CE and CCC. At 480 VAC, VL Circuit Breakers feature N-Class (35 kA), H-Class (65 kA) and L-Class (100 kA) interrupting ratings. They also feature both thermal magnetic and electronic trip units across the entire product line, assuring compatibility for virtually any application. VL Trip Units measure true RMS current. This type of measurement ensures the most accurate means of measuring currents in today's harmonic filled electrical distribution systems.
