Siemens Sentron E1FED42B060 Type ED4 Low Voltage Molded Case Circuit Breaker, 480 VAC, 60 A, 18 kA Interrupt, 2 Poles, ThermalMagnetic Trip


Description

Siemens Sentron Molded Case Circuit Breaker, Type ED4 Low Voltage, 480 VAC, 60 A, 50/60 Hz Frequency, 18 kA Interrupt, ED Frame, Thermal/Magnetic Trip, 2 Pole, Lug Connection, 10 to 1/0 AWG Wire, NEMA 1F Enclosure, Flush Mounting, -25 to 75 deg C, 18 in L x 9 in W x 6 in H Dimensions

Siemens Sentron™ series circuit breakers have a long history of excellent performance in both the commercial and industrial market segments, they are tried and true in the most critical applications. Siemens Sentron™ series circuit breakers are available in nine frame sizes from 125 A to 2000 A.

Features

  • Field installable external accessories
  • Series connected short circuit ratings
  • ED frame with standard breaking capacity in a NEMA type 1 enclosure

Specifications

GTIN: 00783643283336

UNSPSC: 39121601

Country of Origin: Mexico

Number of Poles
2
Voltage Rating
480 VAC
BABA Compliant
No
Type
Type ED4 Low Voltage
Wire Size
10 to 1/0 AWG
Interrupt Rating
18 kA
Enclosure Type
NEMA 1F
Dimensions
18 in L x 9 in W x 6 in H
Mounting Type
Flush
Connection Type
Lug
Amperage Rating
60 A
Temperature Rating
-25 to 75 deg C
Frequency Rating
50/60 Hz
Trip Type
Thermal/Magnetic
Frame
ED
Weight
1710 lbs
Sold as
EACH
