Siemens BQ2M015 Low Voltage Molded Case Circuit Breaker With Insta Wire, 120240 VAC, 15 A, 10 kA Interrupt, 2 Poles, ThermalMagnetic Trip


Description

Siemens Molded Case Circuit Breaker, Low Voltage, 120/240 VAC, 15 A, 10 kA Interrupt, BQ Frame, Thermal/Magnetic Trip, 2 Pole, 14 to 10 AWG Cu/12 to 10 AWG Al Wire, Bolted-On Mounting, 40 deg C, 4 in L x 3 in W x 2 in H Dimensions

Circuit breakers provide a manual means of energizing and de-energizing a circuit. In addition, circuit breakers provide automatic over current protection of a circuit. A circuit breaker allows a circuit to be reactivated quickly after a short circuit or overload is cleared. Unlike fuses, which must be replaced when they open, a simple flip of the breaker's operating handle restores the circuit.

Specifications

GTIN: 00783643238107

UNSPSC: 39121601

Country of Origin: Mexico

BABA Compliant
No
Type
Low Voltage
Interrupt Rating
10 kA
Voltage Rating
120/240 VAC
Dimensions
4 in L x 3 in W x 2 in H
Mounting Type
Bolted-On
Temperature Rating
40 deg C
Frame
BQ
Trip Type
Thermal/Magnetic
Wire Size
14 to 10 AWG Cu/12 to 10 AWG Al
Number of Poles
2
Weight
14 lbs
Amperage Rating
15 A
Sold as
EACH
