Siemens SIMOTICS M A6X30152950 Compact Forced Ventilated AC Motor With Extremely High Power Density, IP55 Enclosure, 44.3 hp, 51 hp, 61.7 hp, 400480 VAC, 475367 Hz, 3 Phase, 70080010001100 rpm Speed, IM B3IM B6IM B7IM B8IM V6 Mount


Description

Siemens SIMOTICS M AC Motor, Compact Forced Ventilated, Series: 1PH8, Crane Motor Application, Permanent Magnet Synchronous, Main Spindle Drive Motor Special Features, 44.3 hp, 51 hp, 61.7 hp, 400/480 VAC, 78/80 A, 47/53/67 Hz Frequency, 3 ph, 700/800/1000/1100 rpm Speed, IP55 Enclosure, 65 mm Dia x 180 mm H Shaft, 439/454/450 N-m Torque, IM B3/IM B6/IM B7/IM B8/IM V6 Mounting, 104 deg F, Insulation Class: Class H, 995 mm L x 364 mm W x 489 mm H Dimensions

The simotics M-1PH8 Series is the latest motor generation for universal use with motion control applications. The wide power range is aimed at use as a central machine drive (as what is known as a "main motor") for various applications. The motors are available as an asynchronous variant as well as a compact synchronous variant with either forced ventilation or water cooling, based on a flexible building block principle. The flexible configuration such as storage or electrical connection technology allows you to adapt the motors to the requirements of almost any industrial application.

Features

  • With DRIVE-CLiQ interface, without 22-bit IC22DQ incremental encoder with commutation position
  • With feather key shaft extension, full key balancing
  • Standard bearing, R/A vibration severity grade according to Siemens/EN 60034-14, R shaft and flange accuracy grade
  • Top terminal box, right cable entry, DE signal connection by looking at de
  • With regreasing system, de and NDE
  • Low space requirements thanks to high power density
  • Performance capability thanks to wide rotational speed setting ranges
  • High degree of structural flexibility due to the choice of asynchronous or synchronous design, forced ventilation or water cooling, mechanical designs
  • Minimized maintenance costs thanks to high bearing service lives
  • Precise motion control thanks to high rotational accuracy, even at the lowest speeds
  • Maximum thermal utilization over the complete speed range
  • Quiet operation as a result of low sound pressure level
  • Optimized for the SINAMICS S120 drive system
  • 44.3 hp, 450 N-m, 80 A at 400 VAC smart/basic line module
  • 51 hp, 454 N-m, 80 A at 400 VAC active line module
  • 61.7 hp, 439 N-m, 78 A at 480 VAC smart/basic/active line module
  • Without holding brake

Specifications

GTIN: 00804766804472

UNSPSC: 26101109

Alternative Part Number: 1PH81842DC001BA1-Z K40+L76

Country of Origin: Czechia

Type
Compact Forced Ventilated
Application Type
Crane Motor
Torque Rating
439/454/450 N-m
Voltage Rating
400/480 VAC
Weight
0.5 lbs
Insulation Class
Class H
Enclosure Type
IP55
Series
1PH8
Phase
3
Special Features
Permanent Magnet Synchronous, Main Spindle Drive Motor
Temperature Rating
104 deg F
BABA Compliant
No
Horsepower
44.3 hp, 51 hp, 61.7 hp
Amperage Rating
78/80 A
Mounting Type
IM B3/IM B6/IM B7/IM B8/IM V6
Dimensions
995 mm L x 364 mm W x 489 mm H
Speed
700/800/1000/1100 rpm
Shaft Size
65 mm Dia x 180 mm H
Frequency Rating
47/53/67 Hz
Sold as
EACH
