Siemens SIMOTICS S A6X30133542 1FK7 Compact Natural Cooling Servomotor With Holding Brake, 0.51 hp, 510 to 720 VDC, 1.4 A, 6000 rpm Speed, IM B5 Flange Mount


Description

Siemens SIMOTICS S Servomotor, Compact Natural Cooling, Series: 1FK7, 0.51 hp, 510 to 720 VDC, 1.4 A, 6000 rpm, IP64 Enclosure, 0.35 in Dia x 0.79 in L Shaft, 0.6 N-m, IM B5 Flange Mount, 104 deg F, Insulation Class: Class F, 2.17 in W

SIMOTICS S-1FK7 motors are permanent magnet excited synchronous motors which are available in the versions compact, high dynamic and high inertia. The motors are characterized by superior overload capability, ruggedness and compactness. The connection via rotatable connectors and preassembled cables ensures a flexible, fast and safe connection to the converter.

Features

  • High degree of efficiency and triple overload capability
  • Shock and vibration-resistant due to mechanically isolated encoder connection
  • Easy to assemble and service due to rotatable connector with quick-release fastener and exchangeable encoder
  • Digital DRIVE-CLiQ interface with electronic rating plate for optimum connection to SINAMICS S120
  • The universal motor for a wide range of applications
  • Space-saving installation through very high power density
  • Large range of motors in the shaft heights 20 to 100

Specifications

GTIN: 00804766532627

UNSPSC: 26101109

Country of Origin: Romania

Type
Compact Natural Cooling
Torque Rating
0.6 N-m
Voltage Rating
510 to 720 V DC
Weight
0.2 lbs
Width
7.6 in
Shaft Size
0.35 in Dia x 0.79 in L
Speed
6000 rpm
Insulation Class
Class F
Enclosure Type
IP64
Dimensions
2.17 in W
Mounting Type
IM B5
Series
1FK7
Amperage Rating
1.4 A
Temperature Rating
104 deg F
Horsepower
0.51 hp
BABA Compliant
No
Sold as
EACH
