Siemens SIMOTICS S A6X30019872 Compact Natural Cooling Servo Motor, 1.4 hp, 3.1 A, 5000 rpm Speed, IM B5IM V1IM V3 Mount

Siemens SIMOTICS S Servo Motor, Compact Natural Cooling, Series: 1FK7, Permanent Magnet Synchronous Special Features, 1.4 hp, 3.1 A, 5000 rpm Speed, IP65/IP67 Enclosure, 19 mm Dia x 48 mm H Shaft, 1.95 N-m Torque, IM B5/IM V1/IM V3 Mounting, 104 deg F, Insulation Class: Class F, 3.78 in W Dimensions

1FK7 motors are extremely compact permanent magnet synchronous motors. The available options, gear units and encoders, together with the expanded product range, mean that the 1FK7 motors can be optimally adapted to any application. They therefore also satisfy the permanently increasing demands of state of the art machine generations. 1FK7 motors can be combined with the SINAMICS S120 drive system to create a powerful system with high functionality. The integrated encoder systems for speed and position control can be selected depending on the application. The motors are designed for operation without external cooling and the heat is dissipated through the motor surface. 1FK7 motors have a high overload capability.
