SIMATIC 6ES72151AG400XB0 S7-1200 Compact Central Processing Unit, 14 Digital/2 Analog Input, 10 Digital/2 Analog Output Input/Output, 125 kB Memory, IP20 Enclosure
SIMATIC 6ES72151AG400XB0 S7-1200 Compact Central Processing Unit, 14 Digital/2 Analog Input, 10 Digital/2 Analog Output Input/Output, 125 kB Memory, IP20 Enclosure
MPN 6ES72151AG400XB0
ASPN SIE6ES72151AG400XB0
UPC 887621769086
Description
Features
- 500 mA, CPU only current consumption
- 1500 mA, maximum CPU with all expansion modules current consumption
- 12 A at 28.8 VDC maximum inrush current
- 1600 mA, maximum 5 VDC for SM and CM for backplane bus (5 VDC)
- 0.08 usec/instruction for bit operations
- 1.7 us/instruction for word operations
- 2.3 us/instruction for floating point arithmetic
- 2 Profinet port, onboard
Specifications
GTIN: 00887621769086
UNSPSC: 32151705
Country of Origin: China
| Type | Compact |
|---|---|
| Width | 5.5 in |
| Enclosure Type | IP20 |
| Memory Size | 125 kB |
| Dimensions | 100 mm H x 130 mm W x 75 mm D |
| Series | S7-1200 |
| Input/Output Capacity | 14 Digital/2 Analog Input, 10 Digital/2 Analog Output |
| BABA Compliant | No |
| Power Supply | 20.4 to 28.8 V DC |
| Number of Configuration Units | 3 Communication Module/1 Signal Board/8 Signal Module |
| Sold as | EACH |
