Siemens Sentron 5SJ4115-7HG40 Miniature Circuit Breaker, 240 VAC, 3 A, 14 kA Interrupt, 1 Poles, ThermalMagnetic Trip
Siemens Sentron 5SJ4115-7HG40 Miniature Circuit Breaker, 240 VAC, 3 A, 14 kA Interrupt, 1 Poles, ThermalMagnetic Trip
MPN 5SJ4115-7HG40
ASPN SIE5SJ41157HG40
UPC 754554929286
Description
Features
- 40 deg C calibration base (industrial applications)
- 30 deg C calibration base
- Can be used for field wiring applications, 14 to 4 AWG, copper (Cu) only
- Suitable for reverse feed applications
- C-trip is designed for general device protection in control circuits and all other miniature circuit breaker systems, magnetic trip point is 5 to 10 times the MCB rating
- 0.75 to 35 sq-mm solid and stranded conductors
- Visible indicator for ON and OFF/trip
- Touch protection to EN50274
- Identical wire screw connections on line and load side
- Smaller size than traditional MCCBs
- 35 mm DIN standard mounting rail
Specifications
GTIN: 00754554929286
UNSPSC: 39121601
Country of Origin: Germany
| Trip Type | Thermal Magnetic |
|---|---|
| Wire Size | 14 to 4 AWG |
| Interrupt Rating | 14 kA |
| Number of Poles | 1 |
| Frequency Rating | 50 Hz |
| Voltage Rating | 240 V AC |
| Actuator Type | Handle |
| Weight | 7.4 lbs |
| Enclosure Type | IP20 |
| Dimensions | 90 mm H x 18 mm W x 70 mm D |
| Mounting Type | DIN Rail |
| Connection Type | Screw |
| Phase | 1 |
| Amperage Rating | 3 A |
| Temperature Rating | -25 to 55 deg C |
| Frame | HSJ |
| BABA Compliant | No |
| Sold as | EACH |
