Siemens 52SA2GABK0J6 Command 52 Class 52 Heavy Duty Non-Illuminated OilWatertight Selector Switch With White Insert, 30 mm, 1NO-3NC Contact, Rotate-UnlatchShort Lever Operator, Black
Siemens 52SA2GABK0J6 Command 52 Class 52 Heavy Duty Non-Illuminated OilWatertight Selector Switch With White Insert, 30 mm, 1NO-3NC Contact, Rotate-UnlatchShort Lever Operator, Black
MPN 52SA2GABK0J6
ASPN SIE52SA2GABK0J6
UPC 783087714274
Description
Features
- New modular design - allowing for quick delivery, multiple distributor options and a full product line for the end user
- Lighting modules, operators, and lens can be ordered fully assembled or independently depending on your applications
- Latest in illumination technology - delivering traditional incandescent lights, energy saving LEDs and energy saving extra bright cluster LEDs
- New ribbed concentric lens - providing improved lighting distribution and aesthetic appeal
- Less mounting space - making Siemens new 30mms smaller than ever
- Silver contacts with gold flashing - improving contact fidelity of all our contact blocks
Specifications
GTIN: 00783087714274
UNSPSC: 39122214
Country of Origin: Mexico
| Cam Code | G |
|---|---|
| Terminal Type | Screw |
| Color | Black |
| Size | 30 mm |
| Weight | 0.7 lbs |
| Contact Mode | Maintained/Rotate-Unlatch |
| Enclosure Type | NEMA 1/3/3R/4/4X/12/13/IP20/IP66 |
| Number of Positions | 3 |
| Operator Type | Short Lever |
| Series | Command 52 |
| Material | Plastic |
| Contact Configuration | 1NO-3NC |
| Environmental Conditions | -35 to 70 deg C Operating, -40 to 85 deg C Storage |
| Finish | Chrome |
| Contact Rating | A600/P600 |
| Bezel/Housing | Metal |
| BABA Compliant | No |
| Type | Class 52 Heavy Duty Non-Illuminated Oil/Watertight |
| Sold as | EACH |
