Sentron 3VA52125ED610AA0 Low Voltage Molded Case Circuit Breaker, 600 VAC500 VDC, 125 A, 18 kA at 600 Y347 V, 35 kA at 480 V, 85 kA at 240 V Interrupt, 2 Poles, TM210 Thermal Magnetic Trip
Sentron 3VA52125ED610AA0 Low Voltage Molded Case Circuit Breaker, 600 VAC500 VDC, 125 A, 18 kA at 600 Y347 V, 35 kA at 480 V, 85 kA at 240 V Interrupt, 2 Poles, TM210 Thermal Magnetic Trip
MPN 3VA52125ED610AA0
ASPN SIE3VA52125ED610AA0
UPC 804766308598
Description
Features
- Compliance with global standards and certifications
- Minimum space requirement thanks to the compact design
- Extensive selection of internal accessories (auxiliary and alarm switches, shunt trips), that are universal to the product line
- Power metering and communication capability with Modbus, PROFIBUS, PROFINET protocols
- Minimal effort for planning and configuration as a result of extensive CAD data
- Knowledge manager- technical information on a specific device can be accessed directly via QR code
- Without auxiliary releases and auxiliary alarm switches
- Without lug terminal
Specifications
GTIN: 00804766308598
UNSPSC: 39121616
Country of Origin: Czechia
| Type | Low Voltage |
|---|---|
| Trip Type | TM210 Thermal Magnetic |
| Interrupt Rating | 18 kA at 600 Y/347 V, 35 kA at 480 V, 85 kA at 240 V |
| Number of Poles | 2 |
| Frequency Rating | 50/60 Hz |
| Voltage Rating | 600 VAC/500 VDC |
| Enclosure Type | IP40 |
| Dimensions | 4.1 in W x 3.3 in D x 7.3 in H |
| Trip Range | 1250 A |
| Amperage Rating | 125 A |
| Volume | 67.4 cubic inches |
| Temperature Rating | -25 to 70 deg C |
| Frame | 3VA52 250 A |
| BABA Compliant | No |
| Sold as | EACH |
