Siemens SIRIUS 3RT20361NP34 3-Phase Standard Power Contactor With Varistor, 175 to 280 VAC/VDC Coil, 50 A, 3NO Contact, 3 Poles
Siemens SIRIUS 3RT20361NP34 3-Phase Standard Power Contactor With Varistor, 175 to 280 VAC/VDC Coil, 50 A, 3NO Contact, 3 Poles
MPN 3RT20361NP34
ASPN SIE3RT20361NP34
UPC 887621916756
Description
Specifications
GTIN: 00887621916756
UNSPSC: 39121529
Country of Origin: Germany
| Type | 3-Phase Standard |
|---|---|
| Operating Temperature | -25 to 60 deg C |
| Terminal Type | Screw |
| Maximum Load Current | 50 A |
| Number of Poles | 3 |
| Wattage | 40 VA Pickup, 2 VA Holding, 23 W DC Closing, 1 W DC Holding |
| Frequency Rating | 50/60 Hz |
| Coil Power Rating | 22 kW at 400 V 3-Phase |
| Size | S2 |
| Width | 3 in |
| Enclosure Type | IP00/IP20 |
| Dimensions | 114 mm H x 55 mm W x 174 mm D |
| Coil Voltage | 175 to 280 V AC/DC |
| Mounting Type | DIN Rail/Snap-On/Threaded |
| Series | 3RT20 |
| Contact Configuration | 3NO |
| Contact Rating | A600/Q600 |
| Operating Cycles | 10000000 |
| Number of Auxiliary Contacts | 2NO-2NC |
| BABA Compliant | No |
| Sold as | EACH |
