SolaHD SDN40-24-480C SDN-C Compact Power Supply, 380/480 VAC Input, 24 VDC Output, 960 W Power Rating, 3 x 1.6 A, DIN Rail Mount


Description

The SolaHD SDN40-24-480C delivers reliable 24 VDC power conversion for industrial control systems with its compact DIN rail design. This switching power supply accepts 380/480 VAC input and provides 960 watts of output power at 40 amps. The unit features three independent 1.6-amp outputs for flexible load distribution across your control panel. DIN rail mounting enables quick installation in standard electrical enclosures. The compact form factor conserves valuable panel space while maintaining high power density for demanding industrial applications.

The SDN-C DIN rail power supplies are the next generation of the popular SDN series. These models combine high efficiency and compact size with new visual diagnostic LEDs to offer the most performance available from SolaHD. Essential industrial features such as sag Immunity, power factor correction, and universal voltage input have been retained in this series. Wide temperature operating range and parallel operation capability make the new SDN-C units suitable to a variety of industrial applications.

Features

  • Compact packaging to save space on the DIN rail via patented DIN rail mounting clip
  • Visual diagnostic LEDs for input and output status at a glance
  • High MTBF means high reliability and long life, higher efficiency saves energy and lowers amount of heat generated in panel
  • PowerBoost™ overload capability to start high inrush loads, active power factor correction
  • User adjustable output voltage accessible via front face
  • Large, rugged, accessible screw terminals
  • Fully tested and burned-in at factory

Specifications

GTIN: 00783472006014

UNSPSC: 39121004

Country of Origin: Philippines (the)

Type
Compact
Output Voltage
24 VDC
Frequency Rating
50/60 Hz
Weight
12.5 lbs
Width
1.97 in
Depth
7.36 in
Input Voltage
380/480 VAC
Height
4.85 in
Mounting Type
DIN Rail
Series
SDN-C
Amperage Rating
3 x 1.6 A
Volume
0
Power Rating
960 W
Case Material
Metal
BABA Compliant
No
Sold as
EACH
