SELECTA® SS206A-BG Heavy Duty Toggle Switch, 125250 VAC, 1510 A, 34 hp, SPST
SELECTA® SS206A-BG Heavy Duty Toggle Switch, 125250 VAC, 1510 A, 34 hp, SPST
MPN SS206A-BG
ASPN SELSS206ABG
UPC 661191109103
Description
Features
- Brass/Nickel actuator
- 1/2 in hole mounting
- 15/32 in dia bushing
- ON/OFF (maintained)
- 0.46 in Dia
Specifications
UNSPSC: 39122211
Country of Origin: United States of America (the)
| Type | Heavy Duty |
|---|---|
| Terminal Type | Screw |
| Number of Poles | 1 |
| Voltage Rating | 125/250 VAC |
| Weight | 70 lbs |
| Dimensions | 1.13 in L x 0.63 in W x 2.26 in H |
| Actuator | Bat Handle |
| Amperage Rating | 15/10 A |
| Contact Configuration | SPST |
| Power Rating | 3/4 hp |
| Mounting | Threaded |
| BABA Compliant | No |
| Sold as |
