Panduit® SCSF250-X Type SCSF Compression Butt Splice, 250 kcmil Conductor, 2-1/2 in L, Flared/Seamless/Standard Barrel, Copper, White


Description

Panduit Compression Butt Splice, Type SCSF, Copper Conductor, 250 kcmil Conductor, 2-1/2 in Length, Flared/Seamless/Standard Barrel, 0.7 in ID x 0.88 in OD Barrel, 35 kV, Specifications: 1-3/16 in L Wire Strip, 90 deg C, Copper, White, Electro-Tin Plated

Panduit® Pan-Term® splices are designed and manufactured for fast assembly and long reliable performance. as the demand for splices increases, it becomes essential to provide a complete system for termination products. we provide an extensive line of tooling designed specifically to provide optimum performance when used as a system for terminating.

Features

  • Color coded barrels marked with Panduit® die index numbers for proper crimp die selection
  • Internal wire stops to prevent over insertion of conductor
  • Tin plated to inhibit corrosion

Specifications

GTIN: 00074983557059

UNSPSC: 39121449

Country of Origin: Mexico

Color
White
Conductor Type
Copper
Barrel Type
Flared/Seamless/Standard
Voltage Rating
35 kV
Specifications
1-3/16 in L Wire Strip
Conductor Size
250 kcmil
Length
2-1/2 in
Material
Copper
Finish
Electro-TiN Plated
Temperature Rating
90 deg C
BABA Compliant
No
Barrel Size
0.7 in ID x 0.88 in OD
Type
Type SCSF
