Panduit Pan-Lug LCAX500-12H-6 LCAX 1-Hole Compression Connector Lug With Inspection Window, 500 kcmil, 535.3 kcmil Extra-Flexible/Flexible/Stranded Copper Conductor, Die Code: P99, 42.767 in Stud, Tin Plated Copper
Panduit Pan-Lug LCAX500-12H-6 LCAX 1-Hole Compression Connector Lug With Inspection Window, 500 kcmil, 535.3 kcmil Extra-Flexible/Flexible/Stranded Copper Conductor, Die Code: P99, 42.767 in Stud, Tin Plated Copper
MPN LCAX500-12H-6
ASPN PANDLCAX50012H6
UPC 74983447916
Description
Features
- Color coded bands for proper die selection and crimp placement
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Tin plated to inhibit corrosion
- Inspection window to visually assure full conductor insertion
- 500 kcmil class G, H, I, K, M and 535.3 kcmil DLO conductor
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Specifications
GTIN: 00074983447916
UNSPSC: 39121405
Country of Origin: Mexico
| Type | 1-Hole |
|---|---|
| Barrel Size | 1.03 in ID x 1.3 in OD x 1.48 in L |
| Color | Pink |
| Overall Length | 3.24 in |
| Tongue Type | 45 deg |
| Conductor Type | Extra-Flexible/Flexible/Stranded Copper |
| Barrel Type | Standard |
| Voltage Rating | 35 kV |
| Weight | 13.9 lbs |
| Specifications | 1-9/16 in L Wire Strip |
| Stud Size | 42.767 in |
| Conductor Size | 500 kcmil, 535.3 kcmil |
| Tongue Size | 1.89 in W x 0.26 in THK |
| Series | LCAX |
| Die Code | P99 |
| Material | Tin Plated Copper |
| Temperature Rating | 90 deg C |
| Mounting Hole Size | 1.56 in |
| BABA Compliant | No |
| Sold as |
