Killark® E-PAK™ EALR-6CGN E Series Type LR Conduit Body With Cover, Neoprene Gasket, 2 in Hub, 70 cu-in Capacity, Aluminum Alloy, Powder Epoxy Painted
Killark® E-PAK™ EALR-6CGN E Series Type LR Conduit Body With Cover, Neoprene Gasket, 2 in Hub, 70 cu-in Capacity, Aluminum Alloy, Powder Epoxy Painted
MPN EALR-6CGN
ASPN KILLEALR6CGN
UPC 783936108810
Description
Features
- Flat back design for easy mounting close to walls
- Cast of high strength, corrosion and weather resistant aluminum alloy with painted finish
- May be used on aluminum or steel conduit
- Lightweight, makes installation simple
- Assembled with cover and gasket to speed installation installer has all components needed
Specifications
GTIN: 00783936108810
UNSPSC: 39131708
Country of Origin: India
| Type | Type LR |
|---|---|
| Color | Gray |
| Width | 1.1 in |
| Dimensions | 9-7/32 in L x 3-7/8 in W x 3-7/16 in H |
| Number of Hubs | 2 |
| Series | E Series |
| Connection Type | Thread |
| Hub Size | 2 in |
| Material | Aluminum Alloy |
| Finish | Powder Epoxy Painted |
| Capacity | 70 cu-in |
| BABA Compliant | No |
| Sold as | EACH |
