GE Q-Line THQC22030WL Type THQC Compact Molded Case Circuit Breaker, 240 VAC, 30 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic/LI/Non-Interchangeable Trip


Description

GE Q-Line Molded Case Circuit Breaker, Type THQC Compact, 240 VAC, 30 A, 50 to 60 Hz Frequency, 10 kA Interrupt, Q-Line Frame, Thermal Magnetic/LI/Non-Interchangeable Trip, 2 Pole, 1 ph, Pivot/Toggle Handle Actuator, Line/Load Lug Connection, 14 to 8 AWG, 12 to 8 AWG Wire, DIN Rail Mounting, 10 to 50 deg C, 2 in W x 2-3/8 in D x 3-9/32 in H Dimensions, Plastic

Q-Line circuit breakers are 1 in W per pole, compact, thermal magnetic devices designed for residential and commercial applications. The QC breakers are lug-lug versions of the Q-Line and are available for 35 mm DIN rail mounting. All Q-Line circuit breakers feature Quick-make/Quick-break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. Q-Line breakers are available in 1, 2 and 3-pole versions and can be ordered with auxiliary contact and shunt trip accessories.

Features

  • Molded case is molded from high mechanical and high dielectric strength engineered plastic
  • Trip indication is shown by handle position midway between ON and OFF, to reset the trip mechanism, move the handle to extreme OFF, then to ON position
  • Quick make, quick break, trip free mechanism minimizes arcing during breaker operation, contacts cannot be ''teased'' into position
  • Trip free mechanism is independent of manual handle control, the breaker trips under short circuit or overload, even though the operating handle is held in ON position
  • VERIFIER™ "Twist-to-Trip" and ''Push-to-Trip'' mechanically simulates over current tripping through actuation of linkages not operated by the ON-OFF handle
  • Common trip bar assures instant disconnect of all conductors when an overload or short circuit occurs on any one conductor in the circuit or an accessory trip device operates
  • Silver alloy contacts combine the conductive properties of silver with other elements for clean, positive electrical contacting, pitting and burning are minimized for longer contact life
  • Arc chutes of heat absorbing, insulating material and metal grid plates quickly ''extinguish'' arcs
  • UL listed lugs for copper or aluminum cable, at full frame rating, easy access and simple, straight-in wiring
  • 10 kA at 120 VAC, 10 kA at 120/240 VAC, 10 kA at 240 VAC interrupt rating

Specifications

GTIN: 00783164012613

UNSPSC: 39121601

Trip Type
Thermal Magnetic
Wire Size
14 to 8 AWG, 12 to 8 AWG
Interrupt Rating
10 kA
Number of Poles
2
Frequency Rating
50 to 60 Hz
Voltage Rating
240 VAC
Actuator Type
Pivot/Toggle Handle
Weight
0.8 lbs
Width
0 in
Dimensions
2 in W x 2-3/8 in D x 3-9/32 in H
Mounting Type
DIN Rail
Connection Type
Line/Load Lug
Phase
1
Material
Plastic
Amperage Rating
30 A
Temperature Rating
10 to 50 deg C
Frame
Q-Line
BABA Compliant
No
Type
Type THQC Compact
Sold as
EACH
