GE TEY3100 Q-Line® Lighting Panel Circuit Breaker, 277/480 VAC, 100 A, 14 kA Interrupt, 3 Poles, LI/Non-Interchangeable Trip


Description

The TEY is a 1 in W per pole, compact, "bolt-on" circuit breaker for use on grounded 480Y/277 VAC systems. the bolt-on mounting base accessory makes the TEY suitable for varied applications as a lug-lug breaker. all TEY circuit breakers feature quick-make quick-break mechanisms, common trip bars and easy to spot trip indication to ensure safety and reliability. TEY breakers are available in 1, 2 and 3-pole versions and can be ordered with auxiliary contact and shunt trip accessories.

Features

  • Standard continuous current rated
  • EY GO schedule
  • Suitable for reverse feed
  • HACR, high intensity discharge (HID) rated special marking
  • 65 kA at 120/240 VAC, 14 kA at 277 VAC interrupt rating

Specifications

GTIN: 00783164182279

UNSPSC: 39121601

Trip Type
Thermal Magnetic
Wire Size
14 to 8 AWG, 12 to 8 AWG
Interrupt Rating
14 kA
Number of Poles
3
Voltage Rating
277/480 VAC
Weight
8.1 lbs
Dimensions
5-1/4 in H x 3 in W x 3-1/16 in D
Mounting Type
Bolted-On
Series
Q-Line®
Connection Type
Load Lug
Phase
3
Amperage Rating
100 A
Volume
115.8 CF
Temperature Rating
40 deg C
Frame
TEY
BABA Compliant
No
Sold as
EACH
