GE 9T58K0050 Core/Coil Dry Fully Encapsulated Harmonic Mitigation Power Transformer, 240/480 VAC Primary, 115 VAC Secondary, 0.5 kVA Power Rating, 60 Hz, 1 ph Phase
GE 9T58K0050 Core/Coil Dry Fully Encapsulated Harmonic Mitigation Power Transformer, 240/480 VAC Primary, 115 VAC Secondary, 0.5 kVA Power Rating, 60 Hz, 1 ph Phase
MPN 9T58K0050
ASPN GE9T58K0050
UPC 783173110201
Description
Features
- Core and coil transformers for machine tool applications are used to provide voltage to control devices in applications where regulation and minimum space are important
- Fully encapsulated coil is impervious to moisture
- Terminal board is anchored in the epoxy for greater reliability
- Wide variety of fusing options
- Rugged, high impact plastic terminal board
- Full head #8 brass screws assure quick, easy terminations with maximum connection integrity
- Flexible design allows input or output voltage to match any application
- Copper windings
- Pressure plate terminals ensure secure connections
- 80 deg C temperature rise
- K1-factor rated transformer
- Terminal board connection
- 180 deg C temperature class
- Fingersafe® terminals offer added protection and safety
Specifications
GTIN: 00783173110201
UNSPSC: 39121028
| Frequency Rating | 60 Hz |
|---|---|
| Enclosure Type | Open |
| Phase | 1 |
| Primary Voltage | 240/480 VAC |
| Temperature Rating | 40 deg C |
| BABA Compliant | No |
| Power Rating | 0.5 kVA |
| Secondary Voltage | 115 VAC |
| Series | 9T58K |
| Insulation | IS-12 |
| Dimensions | 4.56 in W x 3.9 in H |
| Circuit Type | 10225 Frame |
| Type | Core/Coil Dry Fully Encapsulated Harmonic Mitigation |
| Weight | 160.9 lbs |
| Connection Type | Pressure Plate |
| Sold as | EACH |
