General Cable® Carol® E3514S.41.03 Type FPLP Multi-Conductor Plenum Unshielded Fire AlarmLife Safety Cable, Reel Packaging, 300 VAC, (4) 16 AWG Fully Annealed Bare Solid Copper Conductor, 1000 ft L


Description

General Cable® Carol® Fire Alarm/Life Safety Cable, Type FPLP Multi-Conductor Plenum Unshielded, Reel Packaging, 300 VAC, 4 Conductors, Fully Annealed Bare Solid Copper Conductor, 16 AWG Conductor, 0.202 in OD, 1000 ft Length, Flexguard® PVC Insulation, Flexguard® PVC Jacket, Red Jacket, 0 to 75 deg C

Fire alarm systems have expanded from a rather simple and unsophisticated business configured upon large, electromechanical devices to one relying upon the most modern technologies of microprocessor and chip technology. More and more end users industrial, commercial as well as consumer are relying upon these emerging systems to protect both property and life. However, these systems are only as good as their weakest component, whether that component be a processor or interconnecting wire and cable. General Cable? manufactures all Carol? brand fire alarm products of only the finest available materials, provides the service and assurance that the end user not only needs, but requires for use in these and any other systems. Aside from the quality materials used in these designs, specifiers and end users of Carol? brand wire and cable products have come to expect that these cables are registered and certified with the leading regulatory agencies such as underwriters laboratories and we haven't let you down! our Carol? brand designs have proven themselves in the area of fire system security over time, with all being fabricated with solid, bare copper conductors and insulations and jackets of premium-grade PVC. Offered both with and without shields, the former to protect these critical circuits from noise, these cables will provide the latest in available technology for the system installer and contractor.

Features

  • Sequential footage markings to facilitate installation, plenum flame rating
  • Premium grade, color coded Flexguard® PVC insulation
  • Premium grade, Flexguard® PVC red jacket

Specifications

GTIN: 00079407835744

UNSPSC: 26121642

Country of Origin: United States of America (the)

Weight
2.7 lbs
Conductor Size
16 AWG
Length
1000 ft
Number of Conductors
4
Temperature Rating
0 to 75 deg C
BABA Compliant
No
Jacket Color
Red
Voltage Rating
300 VAC
Conductor Type
Fully Annealed Bare Solid Copper
Insulation Material
Flexguard® PVC
Jacket Material
Flexguard® PVC
Packaging Type
Reel
Type
Type FPLP Multi-Conductor Plenum Unshielded
Outside Diameter
0.202 in
Sold as
REEL
