EATON QuickLag BAB3100H Type BAB Miniature Circuit Breaker, 240 V, 100 A, 10 kA Interrupt, 3 Poles, Non-Interchangeable Trip


Description

EATON QuickLag Miniature Circuit Breaker, Type BAB, 240 V, 100 A, 10 kA Interrupt, Non-Interchangeable Trip, 3 Pole, Extended Tang Line/Box Lug Load Connection, 14 to 4 AWG Wire, Bolted-On Mounting, 40 deg C, 2.9 x 3 x 2.9 in Dimensions

EATON bolt-on miniature circuit breakers offer superior protection for panel boards. They are also switching duty rated for 120 VAC fluorescent light applications. Easy to securely install. Choose from 1, 2 or 3-pole designs. Built and listed to UL 489. All products 15 to 100 A are HACR rated. Choose from bolt-on types BAB, QBHW, HBAX and HBAW.

Features

  • Flexible power feed connection
  • Field mountable accessories make installations and on-site custom configuration easy

Specifications

GTIN: 00786679304006

UNSPSC: 39121603

Country of Origin: Dominican Republic (the)

Type
Type BAB
Trip Type
Thermal Magnetic
Wire Size
14 to 4 AWG
Interrupt Rating
10 kA
Number of Poles
3
Voltage Rating
240 VAC
Weight
0.5 lbs
Dimensions
2.9 x 3 x 2.9 in
Mounting Type
Bolt-On
Connection Type
Extended Tang Line/Box Lug Load
Amperage Rating
100 A
Volume
0
Temperature Rating
40 deg C
BABA Compliant
No
Sold as
EACH
