nVent ERICO CADWELD® TAC1V1V Type TA Weld Metal Mold, 2 AWG Concentric Run/Tap Conductor, Cable to Cable Connection, Graphite
nVent ERICO CADWELD® TAC1V1V Type TA Weld Metal Mold, 2 AWG Concentric Run/Tap Conductor, Cable to Cable Connection, Graphite
MPN TAC1V1V
ASPN CADDTAC1V1V
UPC 782856552680
Description
Features
- Forms a permanent, low resistance connection
- Provides a molecular bond
- nVent ERICO CADWELD® exothermic connections are rated with the same current capacity as the conductor
- Portable installation equipment with no external source of power required
- Connections can be visually inspected
- Splice/Grounding Receptacle
Specifications
GTIN: 00782856552680
UNSPSC: 39121457
Country of Origin: United States of America (the)
| Weight | 21 lbs |
|---|---|
| Width | 6.3 in |
| Mold Price Key | C |
| BABA Compliant | No |
| Material | Graphite |
| Connection Type | Cable to Cable |
| Conductor Size | 2 AWG Concentric Run/Tap |
| Specifications | 0.292 in OD Conductor, Horizontal Tee Cable Tap |
| Handle Clamp | L160 |
| Type | Type TA |
| Sold as | BOX |
